Balcany PhotoValtatic System-4PV+Inverter（1200W）+Battery（URA-MESS1）
1.Balcany PhotoValtatic System-4PV+Inverter（1200W）+Battery（URA-MESS1）
2.Battery:URA-MESS1
3.Inverter:
1200W-EWAY-VN4T12
4.Panel:4 Pieces
5.All in one carton packing:
1) Solar panel: 415W*4pcs(full black)
2) Micro-inverter: 1600W*1 pcs
3) Mounting bracket: 1 set
4) AC cable with plug: 5m*1 pcs
1.Balcany PhotoValtatic System-4PV+Inverter（1200W）+Battery（URA-MESS1）
2.Battery:URA-MESS1
3.Inverter:
1200W-EWAY-VN4T12
4.Panel:4 Pieces
5.All in one carton packing:
1) Solar panel: 415W*4pcs(full black)
2) Micro-inverter: 1600W*1 pcs
3) Mounting bracket: 1 set
4) AC cable with plug: 5m*1 pcs
Balcany PhotoValtatic System-4PV+Inverter（1200W）+Battery（URA-MESS1）
| 1600W Micro-inverter | |
| Model | 1200W-EWAY-VN4T12 |
| EWAY VN4T12 is a high-efficiency micro-inverter that can be connected to four solar panels. They are usually installed on the roof, under the panels. The portable micro-inverter is only 3kg and is easy to install. It can also be combined with other EWAY micro-inverters, for optimal flexibility of your PV installation. Highlights: • DC input 1 4A, AC output 1200W • Individual optimization, separate dedicated MPPT for each panel. • New topology design with EU efficiency up to 95.3%. • Suitable for EWAY-ESK series AC module solution. • Plug and Play installation, Easy to install. 1200W-VN4T12 • Max. DC voltage 60V. No threat for high DC voltage. • Integrated LoM protection function. Ensure the safety of power grid. • Die casting design and glue filling technology. Better heat dissipation. • Guaranteed quality with standard 12 years warranty. | |
| Input Data (DC) | |
| Recommended Module Power [W] | 300~550 |
| Start up Voltage per Input [V] | 18 |
| Mppt Voltage Range per Input [V] | 16~60 |
| Max. Input Voltage per Input [V] | 60 |
| Max. Input Current per Input [A] | 14 |
| Max. Input Short-c ircuit Current per Input [A] | 20 |
| Quantity of Mppt | 2 |
| Output Date (AC) | |
| Max. Continous Output Power [VA] | 1200 |
| Nomi nal Continous Output Power [W] | 1200 |
| Nomi nal Output Current [A] | 3.48 |
| Max. Output Current [A] | 7.8 |
| Nomi nal Output Voltage [V] | 220/230/240, L/N/PE |
| Nominal Frequency [Hz] | 50/60 |
| Power Factor | >0.99 default, 0.8 leadi ng... 0.8 lagging |
| Output Current Harmonic Distortion | <3% |
| Max. Units Per Branch | 3 |
| Efficiency | |
| CEC Weighted Efficiency | 95.50% |
| EU E fficiency | 95.30% |
| Mppt | 99.90% |
| Night Time Power Consumption [mW] | <50 |
| Mechanical Data | |
| Dimensions (W*H*D mm) | 342*223*30 |
| Weight [kg] | 3.2 |
