261kWh Liquid-Cooled Energy Storage System - Efficient Power Solution
Intelligent Storage for Demand Management and Cost Savings.
Highly Modularized Design
Rapid Capacity Expansion, 99% Efficiency
industrial-Grade Protection Liquid-Cooled Thermal Management,-20~55℃
Zero-lnterrupton Grid Transition <30ms, Off-Grid Capable
High-Voltage Capacity 168A Fast Charge
125kw off-grid,±0.99 Adjustable PF
Rapid Capacity Expansion, 99% Efficiency
industrial-Grade Protection Liquid-Cooled Thermal Management,-20~55℃
Zero-lnterrupton Grid Transition <30ms, Off-Grid Capable
High-Voltage Capacity 168A Fast Charge
125kw off-grid,±0.99 Adjustable PF
5.0
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
|
Battery Parameters
|
|
|---|---|
|
Battery Type
|
LFP
|
|
Nominal Voltage
|
832V
|
|
Voltage Range
|
741~932V
|
|
Nominal Capacity
|
314Ah
|
|
Nominal Energy
|
261.2kWh
|
|
Max Charge/Discharge Current
|
168A
|
|
AC Grid-Connection Parameters
|
|
|
Voltage Configuration
|
Three-Phase Four-Wire System
|
|
AC Voltage Range
|
400Vac（340Vac~440Vac）
|
|
Nominal Current
|
181A |
|
Maximum Current
|
200A |
|
Nominal Frequency
|
50Hz/60Hz
|
|
Power Factor
|
>0.99 (at half load and above), adjustable range: 1 (leading) to 1 (lagging).
|
|
Charge/Discharge Switching Time
|
<30ms
|
|
Off-grid Parameters①
|
|
|
AC Voltage Harmonics
|
≤3% (linear load)
|
|
Output Frequency
|
50Hz/60Hz
|
|
Rated Output Power
|
125kW
|
|
Maximum Apparent Power
|
137.5kVA
|
|
PV Parameters (Optional)
|
|
|
Maximum Input Voltage
|
950V
|
|
Operating Voltage Range
|
500~950V
|
|
Rated Power
|
125kW
|
|
Maximum Current
|
110/110 |
|
Number of Input Channels
|
2 |
|
Maximum Efficiency
|
99% |
|
General Parameters
|
|
|
Weight
|
~2600kg
|
|
Altitude
|
＜2000m
|
|
Protection Level (IP Rating)
|
IP54
|
|
Corrosion Protection Leve
|
C4
|
|
Dimensions(W*D*H)
|
1000x1590x2350 mm
|
|
Operating Temperature Range
|
﹣20~55℃
|
|
Operating Humidity Range
|
RH ≤ 95% (non-condensing)
|
|
Temperature Control Method
|
Battery: Liquid Cooling Inverter: Air Cooling
|
|
Fire Protection Device
|
Thermal Aerosol
|
①: The off-grid function requires the use of STS accessories.
